IAM Roles and Least Privilege

Scope

This guide covers:

1. IAM identities and principals
2. IAM roles
3. Trust policies
4. Permissions policies
5. AWS STS and temporary credentials
6. Role assumption
7. IAM policy structure
8. Least-privilege design
9. Policy evaluation
10. Permissions boundaries, SCPs, RCPs, and session policies
11. iam:PassRole
12. Cross-account access
13. Workload roles
14. IAM troubleshooting
15. Practical exercises

Learning Outcomes

After completing this guide, you should be able to:

• Explain the difference between an IAM user and an IAM role.
• Explain who can assume a role.
• Distinguish a role's trust policy from its permissions policies.
• Trace the complete AssumeRole process.
• Write resource-scoped IAM policies.
• Apply least privilege across actions, resources, and conditions.
• Explain implicit deny and explicit deny.
• Calculate effective permissions when several policy types apply.
• Explain permissions boundaries and AWS Organizations guardrails.
• Secure iam:PassRole.
• Design IAM roles for EC2, Lambda, CI/CD, and cross-account administration.
• Diagnose an AccessDenied error methodically.

IAM Mental Model

IAM answers two separate questions:

1. Authentication: Who are you?
2. Authorization: What are you permitted to do?

An AWS request can be represented as:

Principal
    performs
Action
    against
Resource
    under
Conditions

Example:

Principal: arn:aws:sts::111122223333:assumed-role/AppRole/i-012345
Action:    s3:GetObject
Resource:  arn:aws:s3:::production-data/reports/july.csv
Condition: Request came through an approved VPC endpoint

AWS builds a request context and evaluates all applicable policies before allowing or denying the action.

The request context may include:

• Principal
• Requested action
• Resource
• Resource tags
• Principal tags
• Network source
• AWS Region
• AWS account
• Organization
• AWS service
• Role session attributes
• Authentication details

A useful model is:

P = Principal
A = Action
R = Resource
C = Condition

For every IAM decision, determine all four.

IAM Identities and Principals

AWS Account Root User

The root user represents the AWS account itself.

It has complete account-level access and should not be used for routine work.

Root credentials must be protected with strong authentication and reserved for tasks that specifically require root access.

Required controls:

• Enable MFA.
• Do not create root access keys.
• Do not use the root account for daily administration.
• Store recovery information securely.
• Monitor root-account activity.
• Use root only for tasks that explicitly require it.

IAM User

An IAM user is a long-lived identity created inside an AWS account.

It may have:

• Console password
• Access key ID
• Secret access key
• Attached permissions policies
• Group membership
• MFA configuration

IAM users are not the preferred design for ordinary workforce access.

Preferred alternatives:

• AWS IAM Identity Center
• SAML federation
• OIDC federation
• Corporate identity providers
• Temporary IAM role sessions

Applications should use IAM roles instead of permanent IAM-user access keys.

IAM Group

An IAM group is a collection of IAM users used for permissions management.

Example:

Group: DatabaseOperators

Members:
- Alice
- Bob
- Carol

Attach a policy to the group, and users in the group receive those permissions.

An IAM group is not an authenticated principal.

An IAM group:

• Cannot sign in.
• Cannot have credentials.
• Cannot assume a role.
• Cannot appear as a Principal in a resource policy.

Groups organize IAM users. They do not represent active sessions.

IAM Role

An IAM role is an AWS identity with permissions but without permanent passwords or access keys.

A trusted principal assumes the role and receives temporary security credentials.

Roles are intended for:

• AWS services
• Applications
• Federated users
• Cross-account access
• CI/CD systems
• Emergency administration
• Temporary elevated access

Unlike an IAM user, a role is not permanently associated with one person.

Principal

A principal is an authenticated entity making an AWS request.

Examples:

IAM user
IAM role session
AWS service
AWS account
Federated identity
AWS STS federated session
OIDC identity
SAML identity

An IAM group is not a principal.

What Is an IAM Role?

An IAM role contains two fundamentally different permission relationships:

Role
├── Trust policy
│   └── Who may assume this role?
│
└── Permissions policies
    └── What may the role do after assumption?

Both sides must be correct.

Trust Policy

The trust policy controls who or what can assume the role.

Example for EC2:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": {
        "Service": "ec2.amazonaws.com"
      },
      "Action": "sts:AssumeRole"
    }
  ]
}

Meaning:

The EC2 service is trusted to assume this role.

The trust policy does not grant access to S3, EC2, databases, or other AWS services.

It only defines the role-assumption relationship.

A role trust policy is a resource-based policy attached to the role.

Permissions Policy

The permissions policy determines what the assumed role can do.

Example:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "ReadApplicationConfiguration",
      "Effect": "Allow",
      "Action": [
        "s3:GetObject"
      ],
      "Resource": [
        "arn:aws:s3:::production-config/app/*"
      ]
    }
  ]
}

Meaning:

A session using this role may read objects under:
s3://production-config/app/

It does not allow:

• Deleting objects
• Uploading objects
• Reading other buckets
• Listing all AWS buckets
• Managing IAM

Both Policies Are Required

Consider an EC2 role:

Trust policy:
EC2 may assume the role.

Permissions policy:
The role may read one S3 prefix.

If the trust policy is wrong:

EC2 cannot obtain the role.

If the permissions policy is wrong:

EC2 obtains the role but cannot perform the required S3 operation.

Role Assumption and AWS STS

AWS Security Token Service

AWS Security Token Service issues temporary credentials for role sessions.

A temporary credential set includes:

Access key ID
Secret access key
Session token
Expiration time

A role does not have a permanently assigned access key.

Credentials are created when the role is assumed.

AssumeRole Flow

Assume a deployment identity needs to assume:

arn:aws:iam::222233334444:role/ProductionDeployRole

The flow is:

1. The caller authenticates using its current identity.
2. The caller requests sts:AssumeRole.
3. AWS evaluates whether the caller may request that role.
4. AWS evaluates the target role trust policy.
5. AWS STS creates a temporary role session.
6. STS returns temporary credentials.
7. The caller uses those credentials for subsequent AWS requests.
8. Requests are evaluated as the assumed-role session.

The resulting principal resembles:

arn:aws:sts::222233334444:assumed-role/ProductionDeployRole/pipeline-1234

This is a role-session ARN, not the original IAM role ARN.

Caller Permission and Target Trust

For conventional cross-account role assumption, both sides are required.

Caller policy in the trusted account:

{
  "Effect": "Allow",
  "Action": "sts:AssumeRole",
  "Resource": "arn:aws:iam::222233334444:role/ProductionDeployRole"
}

Target role trust policy in the trusting account:

{
  "Effect": "Allow",
  "Principal": {
    "AWS": "arn:aws:iam::111122223333:role/CICDPipelineRole"
  },
  "Action": "sts:AssumeRole"
}

Cross-account access requires authorization from both accounts.

Role Sessions

Each role assumption creates a session.

A session can include:

• Session name
• Session duration
• Session tags
• Source identity
• Optional session policy
• External ID for third-party access

Good session names:

github-run-8142
alice@example.com
incident-response-INC1042

Weak session names:

test
admin
session1

Clear session names and source identity improve CloudTrail attribution.

Session Duration

A normal assumable role can be configured with a maximum session duration from one to twelve hours.

The default maximum is usually one hour unless changed.

When one assumed role assumes another role, the resulting chained session is limited to one hour.

Use shorter sessions for:

• Production administration
• Incident response
• Privileged deployment roles
• Security operations

Use longer sessions only where operationally justified.

Common IAM Role Types

Service Role

A service role allows an AWS service to perform actions on your behalf.

Examples:

Lambda execution role
EC2 role
ECS task role
CodeBuild service role
CloudFormation execution role
Step Functions execution role

Example Lambda trust policy:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": {
        "Service": "lambda.amazonaws.com"
      },
      "Action": "sts:AssumeRole"
    }
  ]
}

The permissions policy may then allow:

• Writing CloudWatch Logs
• Reading a specific secret
• Reading from one DynamoDB table
• Publishing to one SNS topic

Service-Linked Role

A service-linked role is a special role linked directly to an AWS service.

AWS defines how the service uses it.

Names commonly resemble:

AWSServiceRoleFor...

Do not treat a service-linked role like a normal application role.

EC2 Role and Instance Profile

For EC2, the role is delivered through an instance profile.

EC2 instance
    ↓
Instance profile
    ↓
IAM role
    ↓
Temporary credentials

Applications on the instance retrieve automatically rotated temporary credentials through the EC2 instance metadata service or through an AWS SDK credential provider.

One IAM role can be assigned to an EC2 instance at a time.

Applications on that instance share the role's permissions.

Therefore, unrelated applications should not normally share one EC2 instance role.

Forbidden:

Hard-coded AWS access key in:
- Application source code
- .env file
- AMI
- User-data script
- GitHub repository
- Docker image

Required:

Attach a workload-specific IAM role and allow the AWS SDK
to retrieve temporary credentials automatically.

ECS Task Role

An ECS task role grants permissions to a specific ECS task or workload.

Do not rely on the EC2 host role for container application permissions when using ECS on EC2.

Separate task roles provide narrower access for each workload.

Cross-Account Role

A cross-account role permits an identity from another AWS account to assume a role in the target account.

Example:

Security account
    ↓ AssumeRole
ProductionAuditRole
    ↓
Read security configuration in production account

This is preferable to creating duplicate IAM users in every account.

Federated Workforce Role

A federated user authenticates through an external identity system such as:

• Microsoft Entra ID
• Okta
• Google Workspace
• Active Directory
• Another SAML provider
• OIDC provider
• AWS IAM Identity Center

After authentication, the user receives temporary AWS role credentials rather than permanent IAM-user credentials.

CI/CD Role

A CI/CD role should be assumed by the pipeline identity.

Examples:

GitHub Actions through OIDC
GitLab CI through OIDC
CodeBuild service role
Jenkins workload role

The role should be scoped to:

• Specific repository
• Specific branch
• Specific environment
• Specific AWS account
• Specific deployment resources
• Specific role-session conditions

IAM Policy Structure

A policy is a JSON document.

Basic structure:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "DescriptiveStatementName",
      "Effect": "Allow",
      "Action": [
        "service:Operation"
      ],
      "Resource": [
        "arn:aws:service:region:account:resource"
      ],
      "Condition": {
        "Operator": {
          "ConditionKey": "ExpectedValue"
        }
      }
    }
  ]
}

Version

Use:

"Version": "2012-10-17"

This is the policy language version, not the date the policy was created.

Statement

A policy contains one or more statements.

Use separate statements when:

• Actions apply to different resource types.
• Conditions differ.
• Effects differ.
• Resource scopes differ.
• You need distinct audit-friendly purposes.

Sid

Sid is an optional statement identifier.

Good:

"Sid": "ReadApplicationArtifacts"

Weak:

"Sid": "Statement1"

Effect

Possible values:

Allow
Deny

Action

The Action identifies AWS API operations.

Examples:

s3:GetObject
ec2:StartInstances
logs:PutLogEvents
secretsmanager:GetSecretValue
sts:AssumeRole

Resource

Resource identifies the resource ARNs affected by the statement.

Examples:

arn:aws:s3:::company-artifacts
arn:aws:s3:::company-artifacts/*
arn:aws:ec2:ap-south-1:111122223333:instance/i-0123456789
arn:aws:secretsmanager:ap-south-1:111122223333:secret:prod/db-*

Some actions do not support resource-level permissions and therefore require:

"Resource": "*"

Do not assume that every use of Resource: "*" is automatically wrong.

Verify whether the specific AWS action supports resource scoping.

Condition

Conditions restrict when an otherwise matching statement applies.

Typical restrictions include:

• Source IP
• VPC endpoint
• Requested Region
• Principal tag
• Resource tag
• Organization ID
• Source account
• Source ARN
• MFA status
• Requested resource tags

Conditions refine permissions. They do not replace proper action and resource scoping.

Identity-Based and Resource-Based Policies

Identity-Based Policy

An identity-based policy is attached to:

• IAM user
• IAM group
• IAM role

It states:

This identity may perform these actions on these resources.

Example:

{
  "Effect": "Allow",
  "Action": "s3:GetObject",
  "Resource": "arn:aws:s3:::company-reports/*"
}

Resource-Based Policy

A resource-based policy is attached to a resource.

Examples:

• S3 bucket policy
• KMS key policy
• SNS topic policy
• SQS queue policy
• Secrets Manager resource policy
• IAM role trust policy

It states:

These principals may perform these actions against this resource.

Example S3 bucket policy fragment:

{
  "Effect": "Allow",
  "Principal": {
    "AWS": "arn:aws:iam::111122223333:role/ReportReaderRole"
  },
  "Action": "s3:GetObject",
  "Resource": "arn:aws:s3:::company-reports/*"
}

Within one account, identity-based and resource-based permissions usually combine as a union, while an applicable explicit deny overrides an allow.

Cross-account access generally requires permission from both the principal's account and the resource-owning account.

Least Privilege

Definition

Least privilege means granting only the permissions required to perform an approved task, with no unnecessary permissions.

It applies to:

Who receives access
Which actions are allowed
Which resources are accessible
Under which conditions
For how long
From which environment

Least-Privilege Dimensions

Use these six dimensions:

Dimension	Question
Principal	Who needs access?
Action	What exact operations are required?
Resource	Which exact resources are required?
Condition	Under what circumstances?
Duration	For how long?
Environment	Development, staging, or production?

Bad Policy

{
  "Effect": "Allow",
  "Action": "*",
  "Resource": "*"
}

Meaning:

All AWS actions against all applicable resources.

This is administrative access.

Slightly Narrower but Still Weak

{
  "Effect": "Allow",
  "Action": "s3:*",
  "Resource": "*"
}

Meaning:

All S3 actions against all S3 resources the account can address.

This may include:

• Deleting objects
• Deleting buckets
• Changing bucket policies
• Changing encryption
• Changing lifecycle configuration
• Replication changes
• Object ownership changes

Properly Scoped S3 Policy

Requirement:

Application may:
- List the reports/ prefix
- Download report objects

Application may not:
- Upload
- Delete
- Read other prefixes
- Access other buckets

Policy:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "ListReportsPrefix",
      "Effect": "Allow",
      "Action": "s3:ListBucket",
      "Resource": "arn:aws:s3:::company-data",
      "Condition": {
        "StringLike": {
          "s3:prefix": [
            "reports",
            "reports/*"
          ]
        }
      }
    },
    {
      "Sid": "ReadReportObjects",
      "Effect": "Allow",
      "Action": "s3:GetObject",
      "Resource": "arn:aws:s3:::company-data/reports/*"
    }
  ]
}

Notice the two resource types:

ListBucket → Bucket ARN
GetObject  → Object ARN

A common IAM error is assigning an object action to a bucket ARN or a bucket action to an object ARN.

Resource-Level Restriction

Weak:

{
  "Effect": "Allow",
  "Action": [
    "secretsmanager:GetSecretValue"
  ],
  "Resource": "*"
}

This could allow reading every accessible secret.

Stronger:

{
  "Effect": "Allow",
  "Action": [
    "secretsmanager:GetSecretValue"
  ],
  "Resource": [
    "arn:aws:secretsmanager:ap-south-1:111122223333:secret:production/payments/database-*"
  ]
}

Stronger with a Region condition:

{
  "Effect": "Allow",
  "Action": "secretsmanager:GetSecretValue",
  "Resource": "arn:aws:secretsmanager:ap-south-1:111122223333:secret:production/payments/database-*",
  "Condition": {
    "StringEquals": {
      "aws:RequestedRegion": "ap-south-1"
    }
  }
}

Role-Based and Attribute-Based Access

Role-Based Access Control

RBAC assigns permissions according to job or workload role.

Examples:

DatabaseOperator
ReadOnlyAuditor
ProductionDeployer
BillingViewer
ApplicationRuntime

Attribute-Based Access Control

ABAC uses attributes such as tags.

Example rule:

Permit access when:
Principal Project tag = Resource Project tag

Conceptual policy:

{
  "Effect": "Allow",
  "Action": [
    "ec2:StartInstances",
    "ec2:StopInstances"
  ],
  "Resource": "*",
  "Condition": {
    "StringEquals": {
      "aws:ResourceTag/Project": "${aws:PrincipalTag/Project}"
    }
  }
}

ABAC can reduce the need to maintain separate policies for every project, provided that tagging is governed correctly.

Tag Security Warning

ABAC fails when users can freely alter authorization tags.

If access depends on:

Project=Payments

then permission to add or modify that tag becomes security-sensitive.

Control:

• Who can create tags
• Who can change authorization tags
• Which tag keys are accepted
• Which tag values are accepted
• Whether tags must be supplied during resource creation

IAM Policy Evaluation

Fundamental Rules

AWS authorization starts with an implicit deny.

No applicable Allow → Denied
Applicable Allow    → Potentially allowed
Applicable Deny     → Denied

The decisive rule is:

Explicit Deny overrides every Allow.

Simplified Evaluation Model

A useful simplified formula is:

Effective permissions =
    permissions granted by identity and resource policies
    intersected with:
        permissions boundary
        session policy
        SCP and RCP guardrails

Then:
    any applicable explicit Deny wins.

More precisely:

Identity-based policy + resource-based policy:
Usually union

Identity policy + permissions boundary:
Intersection

Identity policy + SCP:
Intersection

Role policy + session policy:
Intersection

Example

Role policy:

Allows:
s3:GetObject
s3:PutObject

Permissions boundary:

Allows:
s3:GetObject

SCP:

Allows:
s3:*

Effective permissions:

s3:GetObject

PutObject is not allowed by the permissions boundary.

Explicit Deny Example

Role policy:

Allow s3:GetObject

Bucket policy:

Deny s3:GetObject when the connection is not using TLS

Request without TLS:

Denied

The role's allow cannot override the bucket policy's explicit deny.

Permissions Boundaries

A permissions boundary sets the maximum permissions that an IAM user or role can receive from identity-based policies.

It does not grant permissions by itself.

Identity policy:
What the role has been granted

Permissions boundary:
Maximum permissions the role is permitted to receive

Effective permissions are the intersection of the two.

Example

Developer-created role policy:

Allow:
ec2:*
iam:*
s3:*

Boundary:

Allow:
ec2:Describe*
s3:GetObject
s3:ListBucket

Effective result:

ec2:Describe*
s3:GetObject
s3:ListBucket

The boundary prevents the broad identity policy from becoming fully effective.

Appropriate Use

Permissions boundaries are useful when delegating role creation.

Example:

Platform team:
Creates boundary named WorkloadRoleBoundary

Application teams:
May create their own application roles

Requirement:
Every created role must use WorkloadRoleBoundary

The application team can manage its role policies without exceeding the authorized maximum.

Incorrect Assumption

Boundary allows s3:GetObject
Therefore the role can read S3.

Incorrect.

The identity policy must also allow s3:GetObject.

AWS Organizations Guardrails

Service Control Policy

An SCP limits the maximum available permissions for principals in member accounts of an AWS Organization.

An SCP does not grant permissions.

Example:

SCP denies disabling CloudTrail.

Even an administrator role in that member account cannot disable CloudTrail while the deny applies.

Resource Control Policy

An RCP places organization-level guardrails on supported resources.

Conceptually:

SCP:
Controls the maximum permissions available to principals.

RCP:
Controls the maximum permissions available against resources.

Identity-based or resource-based policies are still required to grant actual permissions.

Guardrail Hierarchy

Organization
└── Organizational Unit
    └── Account
        └── IAM role
            └── Role session

A request may be affected by policies at several levels.

When troubleshooting, do not stop after finding an Allow attached to the role.

Session Policies

A session policy is supplied when creating a temporary STS session.

It can restrict the resulting session further.

Example:

Role normally permits:

Read and write to bucket A
Read from bucket B

Session policy permits:

Read only from bucket A

Effective session:

Read only from bucket A

A session policy cannot expand beyond the role's existing permissions.

Appropriate uses:

• Temporary incident access
• Restricted automation run
• Tenant-specific session
• Per-request scope reduction
• Federated session restriction

iam:PassRole

Purpose

iam:PassRole allows a principal to assign an IAM role to an AWS service.

Examples:

• Launch EC2 with an instance role
• Create Lambda with an execution role
• Create ECS task definition with a task role
• Start CodeBuild with a service role
• Create a CloudFormation stack using an execution role

The service later assumes that role and uses its permissions.

Why It Is Security-Sensitive

Suppose a developer cannot directly delete production data.

However, the developer is allowed to pass this role:

ProductionAdministratorRole

to Lambda.

The developer could:

1. Create a Lambda function.
2. Assign ProductionAdministratorRole.
3. Run code through the Lambda function.
4. Use the role's privileges indirectly.

Therefore, broad iam:PassRole can create a privilege-escalation path.

Forbidden

{
  "Effect": "Allow",
  "Action": "iam:PassRole",
  "Resource": "*"
}

This allows passing any eligible role in the account.

Correct Restriction

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "PassApprovedEC2Roles",
      "Effect": "Allow",
      "Action": [
        "iam:GetRole",
        "iam:PassRole"
      ],
      "Resource": [
        "arn:aws:iam::111122223333:role/application/ec2/*"
      ],
      "Condition": {
        "StringEquals": {
          "iam:PassedToService": "ec2.amazonaws.com"
        }
      }
    }
  ]
}

This restricts:

Which roles may be passed
Which service may receive them

AssumeRole vs PassRole

sts:AssumeRole:

The calling principal becomes a role session.

iam:PassRole:

The calling principal assigns a role to an AWS service.
The AWS service assumes the role later.

They are not equivalent.

Third-Party Cross-Account Roles

When granting a third-party provider access:

Do not create an IAM user with permanent access keys.
Create a cross-account IAM role.

Require:

• Third party's AWS account ID
• Restricted permissions policy
• Restricted trust policy
• Unique external ID
• Auditable role sessions

Trust policy example:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "TrustMonitoringVendor",
      "Effect": "Allow",
      "Principal": {
        "AWS": "arn:aws:iam::444455556666:root"
      },
      "Action": "sts:AssumeRole",
      "Condition": {
        "StringEquals": {
          "sts:ExternalId": "customer-7c83f560-b2fd"
        }
      }
    }
  ]
}

The external ID helps prevent the confused deputy problem, where one customer attempts to trick a multi-tenant provider into using another customer's role.

The external ID should be unique per customer.

It should not be treated as a password or secret.

Confused Deputy Protection for AWS Services

When an AWS service accesses a resource on your behalf, restrict the service principal using context such as:

aws:SourceArn
aws:SourceAccount

Example:

{
  "Effect": "Allow",
  "Principal": {
    "Service": "cloudtrail.amazonaws.com"
  },
  "Action": "s3:PutObject",
  "Resource": "arn:aws:s3:::central-audit-logs/AWSLogs/111122223333/*",
  "Condition": {
    "StringEquals": {
      "aws:SourceAccount": "111122223333"
    }
  }
}

Trusting only a service principal without limiting which customer-owned resource may invoke it can create a cross-service confused deputy risk.

Managed and Inline Policies

AWS Managed Policy

Created and maintained by AWS.

Examples:

ReadOnlyAccess
AmazonS3ReadOnlyAccess
AdministratorAccess

Advantages:

• Quick to adopt
• Maintained by AWS
• Useful during initial setup

Disadvantages:

• Usually broader than a specific workload needs
• May change as AWS updates the policy
• Designed for general reuse rather than your exact architecture

A sensible process is to start with managed policies only where necessary and then replace them with customer-managed, least-privilege policies based on actual usage.

Customer-Managed Policy

Created and maintained in your account.

Advantages:

• Reusable
• Versioned
• Centrally managed
• Can be specific to your architecture
• Easier to audit across several roles

Inline Policy

Embedded directly into one user, group, or role.

Advantages:

• Strong one-to-one relationship
• Deleted with the identity

Disadvantages:

• Harder to reuse
• Harder to inventory consistently
• Can fragment permissions management

Recommended rule:

• Use customer-managed policies for reusable permission sets.
• Use inline policies only where a strict one-to-one policy relationship is intentional and documented.

Least-Privilege Implementation Process

Do not attempt to guess a perfect production policy in one step.

Use a controlled process.

Phase 1: Define the Task

Write the exact workload requirement:

The invoice processor must:
- Read objects from incoming-invoices/
- Write objects to processed-invoices/
- Read one Secrets Manager secret
- Publish failures to one SNS topic

Phase 2: Identify API Actions

Map application operations to AWS API actions:

Read object       → s3:GetObject
Write object      → s3:PutObject
Read secret       → secretsmanager:GetSecretValue
Publish message   → sns:Publish

Phase 3: Identify Resource ARNs

Identify:

Incoming prefix
Processed prefix
Specific secret
Specific SNS topic

Phase 4: Add Conditions

Examples:

• Restrict Region
• Restrict organization
• Restrict resource tags
• Restrict source account
• Restrict source ARN
• Restrict VPC endpoint

Phase 5: Test Allowed Actions

Confirm every required operation succeeds.

Phase 6: Test Forbidden Actions

Confirm:

Delete object → denied
Read unrelated secret → denied
Publish to unrelated topic → denied
Modify IAM → denied

Phase 7: Observe Actual Usage

Use:

• AWS CloudTrail
• IAM last-accessed information
• IAM Access Analyzer policy generation
• IAM Access Analyzer policy validation

Generated policies must still be reviewed and tested before production deployment.

Phase 8: Remove Unused Access

Review periodically:

• Unused actions
• Unused services
• Unused roles
• Old trust relationships
• Unused access keys
• Excessive session durations
• Stale third-party roles

IAM Design Rules

Required

• Human users use federation and temporary credentials.
• Workloads use IAM roles.
• Each workload receives a dedicated role.
• Each role has one clear business or technical purpose.
• Trust policies identify specific trusted principals.
• Permissions list required API actions.
• Resources are scoped to exact ARNs where supported.
• Conditions are added where they materially reduce risk.
• Production and development use separate roles.
• Privileged sessions are short-lived.
• iam:PassRole is restricted to approved roles.
• Access is reviewed using CloudTrail and IAM Access Analyzer.
• Explicit denies are used only as intentional guardrails.

Forbidden Without Written Justification

• Permanent access keys in application code
• AdministratorAccess for application workloads
• "Action": "*" for routine roles
• "Resource": "*" where resource-level permissions are supported
• "Principal": "*" in a role trust policy
• Shared roles across unrelated workloads
• Development roles with production access
• Unrestricted iam:PassRole
• Third-party IAM users with permanent credentials
• Trusting an entire external account without additional safeguards
• Authorization tags that users can freely modify
• Assuming an SCP, boundary, or session policy grants permissions
• Treating a role name as proof that it is safe

Common IAM Failure Scenarios

Scenario 1: Role Cannot Be Assumed

Possible causes:

• Caller lacks sts:AssumeRole.
• Target trust policy does not trust the caller.
• Trust-policy condition fails.
• External ID is missing or incorrect.
• Permissions boundary blocks sts:AssumeRole.
• SCP blocks the operation.
• Role ARN is incorrect.
• Session duration exceeds the role limit.
• Role chaining requested more than one hour.

Scenario 2: Role Assumption Succeeds, but the API Call Fails

Possible causes:

• Role permissions policy does not allow the action.
• Resource ARN is incorrect.
• Required dependent action is missing.
• Resource policy denies access.
• Permissions boundary limits the action.
• Session policy limits the action.
• SCP or RCP limits the action.
• KMS key policy does not allow decryption.
• Condition does not match.
• Explicit deny applies.

Scenario 3: EC2 Application Has No Credentials

Possible causes:

• No instance profile is attached.
• Instance profile contains the wrong role.
• Metadata access is blocked.
• Application SDK is not using the standard credential chain.
• Proxy settings interfere with metadata access.
• Credentials were hard-coded and have expired.
• Role was recently replaced and the application cached old credentials.

Scenario 4: Lambda Cannot Read a Secret

Check:

Lambda execution role
→ secretsmanager:GetSecretValue
→ Exact secret ARN
→ KMS decrypt permission, when required
→ KMS key policy
→ VPC and DNS connectivity where applicable

Do not solve the issue by attaching AdministratorAccess.

Scenario 5: User Can Create Lambda but Cannot Select the Execution Role

Likely cause:

Missing iam:PassRole

Grant iam:PassRole only for the approved execution-role ARN.

Scenario 6: Policy Appears to Allow the Action but AWS Denies It

Likely causes:

• Explicit deny elsewhere
• Permissions boundary
• SCP
• RCP
• Session policy
• Resource-policy condition
• Unsupported resource ARN
• Condition key unavailable in the request
• Wrong principal type
• Wrong account or Region

Scenario 7: Policy Grants More Access Than Expected

Possible causes:

• Another attached policy grants additional permissions.
• Multiple permission sources are aggregated.
• Resource policy grants access directly.
• Wildcard action includes unexpected API operations.
• Wildcard resource includes unrelated resources.
• NotAction was used with Allow.
• ABAC tags are too broadly controllable.

NotAction combined with Allow can unintentionally grant much broader permissions than expected.

IAM Troubleshooting Procedure

Step 1: Identify the Actual Principal

Run:

aws sts get-caller-identity

Example output:

{
  "UserId": "AROAXXXXXXXXX:pipeline-123",
  "Account": "111122223333",
  "Arn": "arn:aws:sts::111122223333:assumed-role/DeployRole/pipeline-123"
}

Do not assume the active principal from the shell username, EC2 username, or local operating-system account.

Step 2: Identify the Exact Denied Action

Extract from the error:

Action:
Resource:
Principal:
Region:
Request conditions:

Example:

Action:    s3:GetObject
Resource:  arn:aws:s3:::company-data/report.csv
Principal: assumed-role/AppRole/i-012345

Step 3: Inspect the Role

aws iam get-role \
  --role-name AppRole

This shows information including the trust policy and maximum session duration.

Step 4: List Managed Policies

aws iam list-attached-role-policies \
  --role-name AppRole

Step 5: List Inline Policies

aws iam list-role-policies \
  --role-name AppRole

Retrieve an inline policy:

aws iam get-role-policy \
  --role-name AppRole \
  --policy-name ApplicationPermissions

Step 6: Check the Permissions Boundary

aws iam get-role \
  --role-name AppRole \
  --query 'Role.PermissionsBoundary'

Step 7: Check Resource Policies

Depending on the resource, inspect:

S3 bucket policy
KMS key policy
SQS queue policy
SNS topic policy
Secrets Manager resource policy
Lambda resource policy

Step 8: Check AWS Organizations Guardrails

Investigate:

SCP
RCP
Organizational Unit inheritance
Account-level guardrails

Step 9: Check Session Restrictions

Determine whether the session was created with:

• Session policy
• Session tags
• Source identity
• External ID
• Reduced duration

Step 10: Check Explicit Denies First

An explicit deny ends the evaluation.

Search all applicable policies for:

"Effect": "Deny"

Then determine whether the action, resource, and conditions match the request.

Step 11: Review CloudTrail

CloudTrail records the caller identity, event name, source, request parameters, and other authorization evidence for supported API activity.

Review the denied event and the preceding role-assumption event.

Step 12: Use Policy Tools

Use:

• IAM Policy Simulator
• IAM Access Analyzer policy validation
• IAM Access Analyzer findings
• Last-accessed information

Policy simulation is useful, but it does not fully reproduce every service-specific runtime condition.

Treat it as supporting evidence, not the sole proof of effective access.

Practical Laboratory

Objective

Create a workload role that can read one S3 prefix and nothing else.

Architecture

EC2 test instance
    ↓ Instance profile
S3ReportReaderRole
    ↓
s3://iam-lab-bucket/reports/*

Required Role Trust Policy

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "TrustEC2",
      "Effect": "Allow",
      "Principal": {
        "Service": "ec2.amazonaws.com"
      },
      "Action": "sts:AssumeRole"
    }
  ]
}

Required Permissions Policy

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "ListReportsPrefix",
      "Effect": "Allow",
      "Action": "s3:ListBucket",
      "Resource": "arn:aws:s3:::iam-lab-bucket",
      "Condition": {
        "StringLike": {
          "s3:prefix": [
            "reports",
            "reports/*"
          ]
        }
      }
    },
    {
      "Sid": "ReadReportObjects",
      "Effect": "Allow",
      "Action": "s3:GetObject",
      "Resource": "arn:aws:s3:::iam-lab-bucket/reports/*"
    }
  ]
}

Required Tests

Test	Expected result
sts get-caller-identity	Shows assumed EC2 role
List reports/	Allowed
Read reports/test.txt	Allowed
Upload to reports/	Denied
Delete reports/test.txt	Denied
Read private/secret.txt	Denied
List all buckets	Denied
Create IAM user	Denied

AWS CLI Tests

aws sts get-caller-identity

aws s3 ls s3://iam-lab-bucket/reports/

aws s3 cp \
  s3://iam-lab-bucket/reports/test.txt \
  /tmp/test.txt

Expected denial:

aws s3 rm \
  s3://iam-lab-bucket/reports/test.txt

Expected denial:

aws s3 cp \
  s3://iam-lab-bucket/private/secret.txt \
  /tmp/secret.txt

Failure-Injection Exercises

Deliberately introduce:

1. Remove s3:GetObject.
2. Use the bucket ARN instead of the object ARN.
3. Change the trust principal from EC2 to Lambda.
4. Remove the instance profile.
5. Add a permissions boundary that excludes S3.
6. Add an explicit deny to the bucket policy.
7. Pass the wrong role to EC2.
8. Restrict access to the wrong prefix.
9. Request an excessive role-session duration.
10. Add an unrestricted iam:PassRole policy and identify the escalation risk.

For each exercise, record:

Symptom
Active principal
Requested action
Requested resource
Applicable policies
Root cause
Correction
Prevention

Architecture Exercise

Design roles for this application:

Internet-facing application
├── GitHub Actions deployment pipeline
├── EC2 application servers
├── S3 artifact bucket
├── Secrets Manager database credential
├── CloudWatch logs
└── RDS database

Deployment Role

May:

• Deploy application artifacts
• Update approved compute resources
• Read deployment configuration
• Pass only the application runtime role

May not:

• Modify account-wide IAM
• Access database credentials
• Delete CloudTrail
• Pass administrator roles
• Modify unrelated environments

Application Runtime Role

May:

• Read the required application secret
• Read approved configuration
• Write application logs
• Access required application data

May not:

• Deploy infrastructure
• Manage IAM
• Read unrelated secrets
• Access development or unrelated production applications
• Modify logging configuration

Read-Only Operations Role

May:

• View infrastructure
• View logs
• View alarms
• View application health

May not:

• Restart resources
• Change policies
• Read secret values
• Modify production

Emergency Role

Must require:

• Strong authentication
• Short session
• Approval process
• Detailed CloudTrail attribution
• Alerting on assumption
• Defined incident purpose
• Post-use review

Interview Questions

What is the difference between an IAM user and an IAM role?

An IAM user is a long-lived identity that may have permanent credentials.

An IAM role has no permanent credentials and is assumed to create temporary role sessions.

What are the two main policy components of a role?

The trust policy defines who can assume the role.

Permissions policies define what the assumed role may do.

Does a trust policy grant S3 access?

No.

It grants or restricts role assumption.

S3 access must be granted through the role's permissions and, where applicable, the resource policy.

What is least privilege?

Grant only the actions, resources, conditions, and duration necessary for an approved task.

What is an implicit deny?

A request is denied because no applicable policy explicitly allows it.

What is an explicit deny?

An applicable policy contains "Effect": "Deny".

It overrides applicable allows.

Does a permissions boundary grant access?

No.

It defines the maximum permissions identity-based policies can grant to the user or role.

Does an SCP grant permissions?

No.

It limits the maximum permissions available to principals in affected member accounts.

What does iam:PassRole do?

It permits a principal to assign an approved role to an AWS service so that the service can assume it later.

Why is broad iam:PassRole dangerous?

It can allow a user to assign a highly privileged role to a service they control and use that service to perform privileged actions indirectly.

Why use an external ID?

To reduce the confused deputy risk when a multi-tenant third party assumes roles in customer accounts.

Why should applications use roles instead of access keys?

Roles provide temporary, automatically rotated credentials and avoid storing permanent credentials in applications.

What happens when an identity policy allows an action but an SCP denies it?

The request is denied.

What is role chaining?

Role chaining occurs when one assumed-role session assumes another role.

The chained session is limited to one hour.

How would you troubleshoot an IAM AccessDenied error?

Identify:

1. Active principal
2. Requested action
3. Requested resource
4. Request context
5. Identity policies
6. Resource policies
7. Trust policy
8. Permissions boundary
9. Session policy
10. SCP and RCP guardrails
11. Conditions
12. Explicit denies

Knowledge Check

Answer without notes:

1. What is a principal?
2. Why is an IAM group not a principal?
3. What is an IAM role?
4. What is a role trust policy?
5. What is a role permissions policy?
6. What does STS issue?
7. What is a role-session ARN?
8. What action is normally used to assume a role?
9. What is the difference between AssumeRole and PassRole?
10. Why should applications not use permanent access keys?
11. What is implicit deny?
12. What is explicit deny?
13. Which takes priority: allow or explicit deny?
14. Does a permissions boundary grant access?
15. Does an SCP grant access?
16. What is a session policy?
17. Why should Resource be narrowed?
18. When is Resource: "*" unavoidable?
19. What is ABAC?
20. Why must tag-modification permissions be controlled?
21. What does an EC2 instance profile do?
22. Can unrelated applications safely share one EC2 role?
23. Why is unrestricted iam:PassRole dangerous?
24. What does an external ID protect against?
25. Why should role-session names be meaningful?
26. What is the role-chaining duration limit?
27. What is the difference between an AWS-managed and customer-managed policy?
28. What tools can identify unused permissions?
29. What policy types must be checked during an access denial?
30. Why is AdministratorAccess inappropriate for application workloads?

Completion Standard

This guide is complete only when you can:

• Draw the IAM role-assumption flow.
• Write an EC2 trust policy from memory.
• Write a resource-scoped permissions policy.
• Explain trust versus permission.
• Explain temporary credentials.
• Explain role sessions.
• Explain implicit and explicit deny.
• Calculate permissions with a boundary.
• Explain SCP and RCP guardrails.
• Secure iam:PassRole.
• Explain cross-account authorization.
• Explain the external-ID requirement.
• Design separate deployment and runtime roles.
• Diagnose at least five IAM failures.
• Prove that required actions succeed.
• Prove that forbidden actions fail.
• Explain why each granted permission exists.
