AWS Networking Fundamentals

A practical, production-focused guide to AWS VPC design, routing, NAT gateways, security controls, packet flow, troubleshooting, and multi-AZ networking.

awsvpcnetworkingdevopscloudsecurity

Scope

This study module covers:

Amazon VPC fundamentals
IPv4 CIDR planning
Public, private and isolated subnets
Route tables and route selection
Internet gateways
NAT gateways
Security groups
Network ACLs
End-to-end packet flow
Network troubleshooting
Production design principles

1. Learning Outcomes

After completing this module, you must be able to:

Explain what an Amazon VPC is.
Design a multi-Availability Zone VPC.
Divide a VPC CIDR block into appropriate subnets.
Distinguish public, private and isolated subnets based on routing.
Explain how an internet gateway provides internet connectivity.
Explain how private workloads access the internet through NAT.
Design highly available NAT gateway routing.
Configure security groups using least privilege.
Explain the difference between security groups and network ACLs.
Trace traffic through every network component.
Diagnose routing, security-group and NACL failures.
Defend every networking decision in a production architecture.

2. Reference Architecture

Use the following architecture throughout this module.

AWS Region
└── VPC: 10.20.0.0/16
    │
    ├── Availability Zone A
    │   ├── Public Subnet A: 10.20.0.0/24
    │   │   ├── Application Load Balancer node
    │   │   └── NAT Gateway A
    │   │
    │   ├── Private App Subnet A: 10.20.10.0/24
    │   │   └── Application workloads
    │   │
    │   └── Isolated DB Subnet A: 10.20.20.0/24
    │       └── Database
    │
    └── Availability Zone B
        ├── Public Subnet B: 10.20.1.0/24
        │   ├── Application Load Balancer node
        │   └── NAT Gateway B
        │
        ├── Private App Subnet B: 10.20.11.0/24
        │   └── Application workloads
        │
        └── Isolated DB Subnet B: 10.20.21.0/24
            └── Database

External connectivity:

Internet
   │
Internet Gateway
   │
Public subnets
   │
Application Load Balancer
   │
Private application subnets
   │
Isolated database subnets

This architecture creates three distinct network tiers:

Tier	Exposure	Main purpose
Public	Direct route to internet gateway	Internet-facing entry and managed egress
Private application	Outbound internet through NAT	Application workloads
Isolated database	No default internet route	Databases and internal data services

3. Amazon VPC Fundamentals

3.1 What is a VPC?

A Virtual Private Cloud is a logically isolated network inside an AWS Region.

A VPC allows you to define:

Private IP address ranges
Subnets
Route tables
Internet access
Private connectivity
Network access controls
DNS behaviour
Connections to other networks

A VPC spans all Availability Zones within one AWS Region. Subnets, however, belong to individual Availability Zones.

For example:

Region: ap-south-1
VPC:    10.20.0.0/16

Availability Zones:
- ap-south-1a
- ap-south-1b
- ap-south-1c

The VPC can contain subnets in any of these Availability Zones.

3.2 Regional versus zonal resources

Understanding the scope of each resource is essential.

Resource	Scope
VPC	Regional
Route table	Regional VPC resource
Internet gateway	Attached to one VPC
Security group	Regional VPC resource
Network ACL	Regional VPC resource associated with subnets
Subnet	One Availability Zone
Standard NAT gateway	One Availability Zone
EC2 network interface	One Availability Zone
Application Load Balancer	Multi-AZ when configured with multiple subnets

A subnet can never span multiple Availability Zones.

3.3 Resources created automatically

When you create a VPC, AWS automatically creates:

A main route table
A default security group
A default network ACL
A default DHCP option set

AWS does not automatically create an internet gateway, NAT gateway or custom route table for a manually created nondefault VPC.

4. IPv4 CIDR Planning

4.1 What is CIDR?

CIDR stands for Classless Inter-Domain Routing.

CIDR notation combines:

Network address / Prefix length

Example:

10.20.0.0/16

The /16 means the first 16 bits identify the network. The remaining 16 bits are available for addresses inside that network.

4.2 Common CIDR sizes

CIDR	Total IPv4 addresses
`/16`	65,536
`/20`	4,096
`/22`	1,024
`/24`	256
`/25`	128
`/26`	64
`/27`	32
`/28`	16

AWS IPv4 subnets can generally range from /16 to /28.

4.3 AWS-reserved addresses

AWS reserves five IPv4 addresses in every subnet.

For:

10.20.10.0/24

AWS reserves:

Address	Purpose
`10.20.10.0`	Network address
`10.20.10.1`	VPC router
`10.20.10.2`	DNS-related use
`10.20.10.3`	Reserved for future use
`10.20.10.255`	Network broadcast address, although broadcast is not supported

Therefore:

Total addresses:     256
Reserved by AWS:       5
Normally usable:     251

4.4 Production CIDR-planning rules

Required

Allocate enough space for future growth.
Keep public, application and database ranges distinguishable.
Reserve unused CIDR ranges for future services.
Avoid overlap with on-premises networks.
Avoid overlap with other VPCs that may later be connected.
Document every allocated range.

Example allocation

VPC: 10.20.0.0/16

10.20.0.0/20   Reserved for public subnets
10.20.16.0/20  Reserved for application subnets
10.20.32.0/20  Reserved for database subnets
10.20.48.0/20  Reserved for platform services
10.20.64.0/18  Reserved for future growth

The actual subnets can be smaller subdivisions within those ranges.

4.5 Why overlapping CIDRs are dangerous

Assume:

VPC A: 10.20.0.0/16
VPC B: 10.20.0.0/16

If these VPCs later need VPC peering or Transit Gateway connectivity, routing becomes ambiguous because both networks use the same destination range.

Overlapping CIDRs commonly prevent or complicate:

VPC peering
Transit Gateway routing
Site-to-Site VPN connectivity
Direct Connect connectivity
Kubernetes pod-network integration
Mergers between separate AWS environments

CIDR planning is therefore an architectural decision, not a temporary setup task.

5. Subnets

5.1 What is a subnet?

A subnet is a portion of a VPC’s IP address range assigned to one Availability Zone.

Example:

VPC:                 10.20.0.0/16
Public Subnet A:     10.20.0.0/24
Public Subnet B:     10.20.1.0/24
Private App A:       10.20.10.0/24
Private App B:       10.20.11.0/24
Private Database A:  10.20.20.0/24
Private Database B:  10.20.21.0/24

A subnet is not inherently public or private when it is created.

Its effective classification is determined primarily by its route table.

6. Public Subnets

6.1 Definition

A subnet is public when its associated route table contains a route to an internet gateway.

Typical IPv4 route:

Destination: 0.0.0.0/0
Target:      igw-123456789

0.0.0.0/0 means every IPv4 destination not matched by a more specific route.

AWS classifies a subnet as public when it has a route to an internet gateway.

6.2 A public subnet does not automatically make an instance public

For an EC2 instance to communicate directly with the IPv4 internet, all of the following must be true:

The subnet route table has a route to an internet gateway.
The internet gateway is attached to the VPC.
The instance has a public IPv4 address or Elastic IP address.
The security group permits the traffic.
The network ACL permits the traffic.
The instance operating-system firewall permits the traffic.
The application is listening on the required interface and port.

A missing condition will prevent connectivity.

6.3 Appropriate resources for public subnets

Public subnets should contain resources that genuinely require direct internet routing.

Typical examples:

Internet-facing Application Load Balancers
Public NAT gateways
Internet-facing Network Load Balancers
Controlled bastion hosts
Public network appliances

6.4 Resources that should not normally be public

The following should normally remain in private or isolated subnets:

Application servers
Kubernetes worker nodes
EKS nodes
Databases
Redis clusters
Elasticsearch or OpenSearch data nodes
Message brokers
Internal administrative applications
Monitoring systems
Internal APIs

A server does not need a public IP merely because users access its application. Users can access it through a public load balancer.

7. Private Application Subnets

7.1 Definition

A private subnet does not have a direct route to an internet gateway.

A private application subnet may instead use a NAT gateway for outbound internet access.

Example:

Destination: 10.20.0.0/16
Target:      local

Destination: 0.0.0.0/0
Target:      nat-123456789

7.2 Why application workloads require outbound access

Private application workloads may need to:

Download software updates
Pull container images
Access third-party APIs
Contact package repositories
Retrieve external certificates
Send logs to external systems
Access public AWS service endpoints

A NAT gateway allows these workloads to initiate outbound connections without assigning public IPv4 addresses to them. External systems cannot initiate unsolicited connections through the NAT gateway.

7.3 Private does not mean disconnected

A private subnet can still communicate with:

Other subnets in the same VPC
Peered VPCs
Transit Gateway attachments
On-premises networks
AWS services through VPC endpoints
The internet through NAT
Internal load balancers

“Private” means there is no direct internet-gateway route for the subnet.

8. Isolated Subnets

8.1 Definition

An isolated subnet has no default route to:

An internet gateway
A NAT gateway
Another internet-egress system

Example route table:

Destination: 10.20.0.0/16
Target:      local

An isolated subnet can still communicate with other permitted resources inside the VPC through the local route.

8.2 Appropriate isolated-subnet resources

Relational databases
Internal caches
Internal message brokers
Data-processing systems
Sensitive administrative services
Internal certificate authorities

8.3 Why databases usually do not need internet access

A production database should normally receive application connections and communicate with tightly defined internal services.

It usually does not need unrestricted access to:

0.0.0.0/0

Removing the default internet route reduces:

Exfiltration paths
Malware command-and-control access
Accidental external connections
Exposure caused by future configuration errors

Updates, backups and monitoring should preferably use managed AWS mechanisms, internal endpoints or explicitly controlled paths.

9. Route Tables

9.1 Purpose

A route table determines where traffic is sent based on its destination IP address.

Each route contains:

Destination → Target

Examples:

10.20.0.0/16 → local
0.0.0.0/0    → Internet Gateway
0.0.0.0/0    → NAT Gateway
10.50.0.0/16 → VPC Peering Connection
10.60.0.0/16 → Transit Gateway

Every subnet must use one subnet route table. A subnet may be explicitly associated with a custom route table; otherwise, it uses the VPC’s main route table. A route table may be associated with multiple subnets, but a subnet can use only one subnet route table at a time.

9.2 Local route

Every route table contains a local route for its VPC CIDR.

Example:

Destination: 10.20.0.0/16
Target:      local

This allows communication between resources inside the VPC.

For example:

Application: 10.20.10.25
Database:    10.20.20.30

The route to 10.20.20.30 matches:

10.20.0.0/16 → local

The traffic therefore remains within the VPC.

Security groups and network ACLs still apply. A route existing does not guarantee the traffic is permitted.

9.3 Main route table

Every VPC has one main route table.

Any subnet without an explicit custom-route-table association uses the main route table.

Recommended production pattern

Keep the main route table restrictive:

10.20.0.0/16 → local

Explicitly associate every subnet with a purpose-specific custom route table.

This prevents a newly created subnet from accidentally inheriting internet access.

AWS recommends explicit route-table control as a way to reduce unintended routing.

9.4 Custom route tables

Create separate route tables where routing behaviour differs.

Recommended design:

rt-public
rt-private-app-a
rt-private-app-b
rt-isolated-db

This makes routing intent explicit.

9.5 Public route table

Associated with public subnets:

Destination	Target	Purpose
`10.20.0.0/16`	`local`	Internal VPC traffic
`0.0.0.0/0`	Internet gateway	IPv4 internet traffic

For IPv6:

Destination	Target
`::/0`	Internet gateway

IPv4 and IPv6 require separate routes. An IPv4 default route does not cover IPv6 traffic.

9.6 Private application route table

For Availability Zone A:

Destination	Target
`10.20.0.0/16`	`local`
`0.0.0.0/0`	NAT Gateway A

For Availability Zone B:

Destination	Target
`10.20.0.0/16`	`local`
`0.0.0.0/0`	NAT Gateway B

9.7 Isolated database route table

Destination	Target
`10.20.0.0/16`	`local`

There is no default route to the internet.

9.8 Longest-prefix matching

When several routes match a destination, AWS selects the most specific route.

Example:

10.20.0.0/16  → local
10.20.10.0/24 → firewall
0.0.0.0/0     → NAT gateway

Destination:

10.20.10.25

Matching routes:

10.20.0.0/16
10.20.10.0/24
0.0.0.0/0

The /24 route wins because it is the most specific.

Priority:

/32 > /24 > /16 > /8 > /0

AWS uses longest-prefix matching before applying additional route-priority rules.

9.9 Default routes

IPv4:

0.0.0.0/0

IPv6:

::/0

A default route matches any destination that does not have a more specific route.

It is commonly used for:

Internet gateway
NAT gateway
Transit Gateway
Firewall appliance

9.10 Blackhole routes

A route may display a blackhole state when its target is unavailable or deleted.

Examples:

Deleted NAT gateway
Deleted VPC peering connection
Deleted network interface
Detached gateway

Traffic matching a blackhole route is discarded.

9.11 Route tables do not act as firewalls

Route tables answer:

Where should this packet be sent?

They do not answer:

Is this packet authorized?

Authorization is handled by components such as:

Security groups
Network ACLs
AWS Network Firewall
Operating-system firewalls
Application authentication

10. Internet Gateways

10.1 Purpose

An internet gateway allows communication between a VPC and the internet.

It is:

Horizontally scaled
Redundant
Highly available
Managed by AWS
Attached to a VPC
A target in route tables

An internet gateway supports both IPv4 and IPv6 traffic.

10.2 Configuration sequence

To enable direct IPv4 internet access:

Create an internet gateway.
Attach it to the VPC.
Add a route to it from the public route table.
Associate the route table with the public subnet.
Assign the resource a public IPv4 address or Elastic IP.
Permit traffic through security groups.
Permit traffic through network ACLs.

Example route:

0.0.0.0/0 → igw-123456789

10.3 IPv4 address translation

An EC2 instance is aware of its private IPv4 address.

For direct public IPv4 access, the internet gateway performs one-to-one address translation between:

Instance private IPv4 address
        ↕
Instance public IPv4 address or Elastic IP

AWS documents this translation as part of internet-gateway IPv4 connectivity.

10.4 What an internet gateway does not do

An internet gateway does not:

Automatically make all subnets public
Assign public IP addresses
Replace a NAT gateway
Act as a security group
Inspect application-layer traffic
Authenticate users
Protect a poorly configured public server

10.5 Common internet-gateway failure modes

Failure: gateway not attached

The route may exist in configuration, but the VPC cannot use an unattached internet gateway.

Failure: no default route

The gateway exists, but the subnet route table has no route to it.

Failure: no public IPv4 address

The instance has only a private IPv4 address and cannot directly communicate over the IPv4 internet gateway.

Failure: security group blocks traffic

Routing is correct, but the resource firewall denies the required port.

Failure: restrictive NACL

The inbound request or outbound return traffic is denied.

11. NAT Fundamentals

11.1 What is NAT?

NAT means Network Address Translation.

For typical private-subnet internet access, the NAT gateway translates:

Private source address
        ↓
NAT gateway public address

Example:

Private instance: 10.20.10.25
NAT Elastic IP:   203.0.113.10
External server:  198.51.100.20

Original outbound packet:

Source:      10.20.10.25
Destination: 198.51.100.20

Translated packet:

Source:      203.0.113.10
Destination: 198.51.100.20

The NAT gateway maintains translation state so the response can be returned to the original private workload.

11.2 Why NAT is necessary for private IPv4 addresses

Private IPv4 ranges are not routable over the public internet.

Common private ranges include:

10.0.0.0/8
172.16.0.0/12
192.168.0.0/16

An internet server cannot return traffic directly to 10.20.10.25.

The NAT gateway replaces that source address with an internet-routable public address.

11.3 NAT gateway traffic path

Private EC2 instance
    ↓
Private subnet route table
    ↓
NAT gateway
    ↓
Public subnet route table
    ↓
Internet gateway
    ↓
Internet

Return path:

Internet
    ↓
Internet gateway
    ↓
NAT gateway
    ↓
Private EC2 instance

11.4 NAT is outbound-initiated connectivity

A private workload can initiate:

Private instance → Internet

The internet cannot initiate an unsolicited connection through the NAT gateway:

Internet → NAT gateway → Private instance

The second path is not permitted because no matching NAT connection state exists.

11.5 Public NAT gateway requirements

A traditional public zonal NAT gateway requires:

Placement in a public subnet
An Elastic IP address
An internet gateway attached to the VPC
A public-subnet route to the internet gateway
A private-subnet route to the NAT gateway

The NAT gateway itself does not use a security group.

Network ACLs associated with its subnet still affect traffic.

11.6 NAT gateway is not a firewall

NAT provides address translation and connection-state mapping.

It does not provide full security-policy enforcement.

It does not replace:

Security groups
Network ACLs
AWS Network Firewall
Secure web gateways
TLS
Authentication
Egress filtering
DNS filtering

A compromised instance can initiate malicious outbound traffic through NAT unless other controls prevent it.

12. NAT Gateway High Availability

12.1 Zonal NAT gateways

A standard NAT gateway belongs to one Availability Zone and is redundant within that zone.

AWS recommends deploying a NAT gateway in each Availability Zone when private workloads span multiple Availability Zones.

Correct design:

Private Subnet A → NAT Gateway A
Private Subnet B → NAT Gateway B

12.2 Why one shared NAT gateway is a problem

Assume:

NAT Gateway A is in Availability Zone A.
Private Subnet B is in Availability Zone B.
Private Subnet B routes through NAT Gateway A.

Problems:

Availability Zone A becomes an egress dependency for workloads in Zone B.
If Zone A fails, Zone B loses internet egress.
Traffic crosses Availability Zone boundaries.
Cross-zone data-processing charges may apply.
The architecture contradicts zonal fault isolation.

12.3 Laboratory design versus production design

Cost-controlled laboratory

Private Subnet A ─┐
                  ├→ NAT Gateway A
Private Subnet B ─┘

Allowed only when documented as:

Non-production
Not zone-independent
Cost-optimized for temporary learning
A deliberate single point of failure

Production design

Private Subnet A → NAT Gateway A
Private Subnet B → NAT Gateway B

12.4 NAT gateway scaling considerations

Standard NAT gateways automatically scale bandwidth and packet-processing capacity within documented limits. Each IPv4 address also has a finite number of simultaneous connections to a unique destination. High-volume systems may require additional IP addresses, NAT gateways or workload distribution.

Potential symptoms of NAT resource exhaustion include:

Intermittent outbound connection failures
Connections failing only to a popular destination
Increased error rates under load
Port-allocation errors
Packet drops

13. Regional NAT Gateways

AWS also provides Regional NAT Gateways.

A Regional NAT Gateway:

Uses one NAT gateway identifier across Availability Zones
Automatically expands according to workload placement
Maintains zonal affinity
Does not require placement in a public subnet
Has its own route table
Provides high availability by default
Supports higher address limits than zonal NAT gateways

Regional NAT Gateways are intended to simplify multi-AZ internet egress. They do not support private NAT use cases.

13.1 Recommended learning order

First master the standard zonal model because:

It remains widely deployed.
It teaches route-table relationships clearly.
It exposes Availability Zone dependencies.
It appears frequently in existing production architectures.
It remains necessary for some private NAT use cases.

Then compare it with Regional NAT Gateway architecture.

13.2 Zonal versus Regional NAT Gateway

Characteristic	Zonal NAT Gateway	Regional NAT Gateway
Availability scope	One AZ	Expands across AZs
Public subnet required	Yes for public zonal NAT	No
Separate NAT per AZ	Recommended	Not required
Single NAT identifier across AZs	No	Yes
Private NAT support	Yes, using the applicable zonal mode	No
Zonal routing management	Customer-managed	More automated

14. NAT Cost Controls

NAT gateways can generate costs through:

Hourly gateway charges
Data-processing charges
Cross-AZ traffic
Internet data transfer
Unnecessary traffic to public AWS endpoints

14.1 Reduce NAT traffic with VPC endpoints

Private workloads often access services such as:

Amazon S3
DynamoDB
Systems Manager
Elastic Container Registry
CloudWatch
Secrets Manager

Instead of routing every request through NAT, use appropriate VPC endpoints.

Benefits:

Reduced NAT processing charges
Private network paths
Reduced internet dependency
Tighter endpoint policies
Better security boundaries

14.2 Production cost-review questions

Does every private subnet actually require internet access?
Can S3 and DynamoDB use gateway endpoints?
Can AWS APIs use interface endpoints?
Is cross-AZ NAT traffic occurring?
Is one NAT gateway being retained in an unused environment?
Are development NAT gateways running continuously?
Can development environments be destroyed outside working hours?

15. IPv6 Egress

IPv6 addresses are globally unique and do not require traditional IPv4 NAT for internet routing.

For outbound-only IPv6 internet access, AWS provides an egress-only internet gateway.

The traffic model is:

Private IPv6 workload
    ↓
Egress-only internet gateway
    ↓
Internet

It permits the workload to initiate outbound IPv6 connections while preventing unsolicited inbound connections.

Do not assume an IPv4 NAT gateway is automatically the correct IPv6 design.

16. Security Groups

16.1 Purpose

A security group is a stateful virtual firewall attached to supported resources through their network interfaces.

Security groups control:

Inbound traffic
Outbound traffic
Protocols
Ports
Source CIDRs
Destination CIDRs
Source security groups
Destination security groups
Managed prefix lists

16.2 Security-group characteristics

Security groups:

Are stateful
Support allow rules
Do not support explicit deny rules
Operate at resource or network-interface level
Aggregate when multiple security groups are attached
Automatically apply rule changes
Track established connections

New security groups start with no inbound rules and normally include an outbound allow-all rule.

16.3 Stateful behaviour

Assume an instance is allowed to initiate an HTTPS connection:

Instance → External API TCP 443

The outbound request is allowed by the outbound rule.

Because the security group is stateful, the response is allowed back even when there is no corresponding inbound rule for the client’s ephemeral port.

Stateful does not mean unrestricted. It means return traffic associated with an accepted connection is automatically recognized.

16.4 No explicit deny rules

A security group rule can say:

ALLOW TCP 443 from 203.0.113.0/24

It cannot say:

DENY TCP 443 from 198.51.100.0/24

To apply an explicit subnet-level deny, use a NACL or another suitable security-control layer.

16.5 Rule aggregation

If an EC2 instance has two security groups:

Security Group A:
ALLOW TCP 22 from 10.0.0.0/8

Security Group B:
ALLOW TCP 443 from 0.0.0.0/0

The effective rules allow both:

TCP 22 from 10.0.0.0/8
TCP 443 from 0.0.0.0/0

Security groups are additive.

Attaching a restrictive security group does not override a permissive security group.

16.6 Security-group references

Instead of allowing an entire CIDR block, a rule may reference another security group.

Example:

app-sg inbound:
TCP 8080 from alb-sg

This means resources associated with alb-sg may send traffic to resources associated with app-sg on TCP port 8080, subject to routing and other controls.

The reference does not create a network route. Routing must already exist.

16.7 Why security-group references are preferable

Compare:

ALLOW TCP 8080 from 10.20.0.0/16

with:

ALLOW TCP 8080 from alb-sg

The CIDR rule allows every resource in the entire VPC range.

The SG-reference rule permits only resources that are members of the intended security group.

This creates a logical service relationship:

Load balancer tier → Application tier
Application tier   → Database tier

17. Recommended Security-Group Design

17.1 Load balancer security group

Name:

prod-alb-sg

Inbound:

Protocol	Port	Source	Purpose
TCP	443	`0.0.0.0/0`	Public HTTPS
TCP	443	`::/0`	Public IPv6 HTTPS, when enabled

Optional HTTP redirect:

Protocol	Port	Source
TCP	80	`0.0.0.0/0`

Port 80 should redirect to HTTPS rather than serving sensitive application traffic directly.

Outbound:

Protocol	Port	Destination
TCP	8080	`prod-app-sg`

17.2 Application security group

Name:

prod-app-sg

Inbound:

Protocol	Port	Source
TCP	8080	`prod-alb-sg`

This prevents direct application access from arbitrary internet or VPC sources.

Outbound:

Protocol	Port	Destination
TCP	5432	`prod-db-sg`
TCP	443	Required destinations or controlled egress path
UDP/TCP	53	Approved DNS path where applicable

17.3 Database security group

Name:

prod-db-sg

Inbound:

Protocol	Port	Source
TCP	5432	`prod-app-sg`

For MySQL:

TCP 3306 from prod-app-sg

For Microsoft SQL Server:

TCP 1433 from prod-app-sg

Database access from the internet is forbidden:

TCP 5432 from 0.0.0.0/0

17.4 Administrative access

Avoid exposing SSH to the internet.

Preferred methods include:

AWS Systems Manager Session Manager
Controlled VPN access
Zero-trust access platform
Temporary, audited bastion access

Forbidden default:

TCP 22 from 0.0.0.0/0

If temporary SSH is unavoidable:

TCP 22 from administrator-public-ip/32

Remove the rule immediately after use.

18. Security-Group Egress

18.1 Default behaviour

A newly created security group normally permits all outbound traffic:

All protocols
All ports
Destination: 0.0.0.0/0

This is convenient but may be broader than production requirements.

18.2 Restrictive egress

A hardened application security group may permit only:

Database connections
HTTPS to approved services
DNS
Monitoring endpoints
Internal service ports

However, restrictive egress must be implemented carefully because applications frequently depend on:

DNS resolution
Certificate validation
Operating-system repositories
Time synchronization
Container registries
Cloud APIs
Monitoring and logging endpoints

Implement egress restriction with an explicit dependency inventory.

18.3 Security groups do not filter all special AWS traffic

Security groups cannot filter certain traffic to the Amazon-provided Route 53 Resolver. DNS control for that resolver requires Route 53 Resolver DNS Firewall or another appropriate DNS-control mechanism.

19. Network ACLs

19.1 Purpose

A network ACL is a stateless packet filter associated with one or more subnets.

A NACL controls traffic entering and leaving the subnet boundary.

Each subnet must be associated with one NACL. If no custom NACL is assigned, the subnet uses the VPC’s default NACL.

19.2 Characteristics

Network ACLs:

Operate at subnet level
Are stateless
Have separate inbound and outbound rule sets
Support allow and deny rules
Process rules in numerical order
Stop at the first matching rule
Apply to all relevant resources in associated subnets
Require explicit return-path rules

19.3 Default network ACL

The default VPC NACL initially permits all inbound and outbound traffic.

It also contains an unchangeable final * deny rule.

Simplified inbound:

100 ALLOW ALL from 0.0.0.0/0
*   DENY  ALL

Simplified outbound:

100 ALLOW ALL to 0.0.0.0/0
*   DENY  ALL

19.4 Custom network ACL

A newly created custom NACL normally denies traffic until allow rules are added.

Every NACL has a final unmatched-traffic deny rule:

* DENY ALL

19.5 Rule evaluation

Rules are evaluated from the lowest number upward.

Example:

100 DENY  TCP 22 from 203.0.113.0/24
200 ALLOW TCP 22 from 0.0.0.0/0
*   DENY  ALL

Traffic from:

203.0.113.25

matches rule 100 and is denied.

AWS does not continue to rule 200.

Traffic from:

198.51.100.25

does not match rule 100. It matches rule 200 and is allowed.

AWS applies the first matching NACL rule.

19.6 Recommended numbering convention

Use intervals to leave room for future rules.

Example:

100 Allow primary traffic
110 Allow secondary traffic
120 Allow health checks
200 Deny known malicious range
300 Allow remaining approved traffic
*   Deny everything else

Do not number every rule consecutively:

This makes later insertion difficult.

20. Stateless Behaviour and Ephemeral Ports

20.1 What stateless means

A NACL does not remember previous packets.

Suppose a client initiates:

Client:50000 → Server:443

The request arrives at destination port 443.

The response is:

Server:443 → Client:50000

The response targets the client’s ephemeral port, 50000.

A stateless NACL must allow both directions independently.

20.2 Example: Public web server

Inbound rule:

ALLOW TCP 443 from 0.0.0.0/0

Outbound return rule:

ALLOW TCP 1024-65535 to 0.0.0.0/0

Without the outbound ephemeral-port rule:

The client request may reach the server.
The server response may be denied.
The connection appears to time out.

20.3 Example: Private client accessing HTTPS

A private instance initiates:

Private instance:50000 → External server:443

Private-subnet outbound NACL:

ALLOW TCP 443 to 0.0.0.0/0

Private-subnet inbound return rule:

ALLOW TCP 1024-65535 from 0.0.0.0/0

Custom NACLs require corresponding return-traffic rules.

20.4 Ephemeral ranges vary

The exact ephemeral-port range depends on:

Client operating system
Kernel configuration
Load balancer behaviour
NAT behaviour
AWS service

A broad training rule often uses:

1024-65535

In production, determine the actual required range before narrowing it.

21. Security Groups versus Network ACLs

Characteristic	Security group	Network ACL
Attachment level	Resource or ENI	Subnet
State handling	Stateful	Stateless
Rule actions	Allow only	Allow and deny
Evaluation	Combined set of rules	Lowest-numbered first match
Return traffic	Automatically tracked	Explicit rules required
SG references	Supported	Not supported
Main purpose	Workload access control	Coarse subnet guardrail
Multiple controls	Rules aggregate	One NACL per subnet
Typical failure	Missing port or wrong source	Missing return or ephemeral-port rule

21.1 Primary-control rule

Use security groups as the primary workload access-control system.

Use NACLs for requirements such as:

Blocking a known malicious CIDR across an entire subnet
Enforcing broad subnet boundaries
Adding defence in depth
Meeting a specific compliance control
Applying stateless network restrictions

AWS supports operating with security groups as the primary resource-level control and NACLs as an additional subnet-level layer.

21.2 Do not duplicate every rule unnecessarily

Creating identical complex rules in both security groups and NACLs increases:

Operational complexity
Troubleshooting difficulty
Risk of asymmetric return-path failures
Configuration drift
Change-management overhead

Use each mechanism for its appropriate responsibility.

22. Complete Packet-Flow Analysis

22.1 Internet user to application

Assumptions:

User public IP:       198.51.100.10
ALB public endpoint:  Publicly resolvable
Application IP:       10.20.10.25
Application port:     8080

Path:

1. User resolves application DNS name.
2. DNS returns the public ALB addresses.
3. User sends TCP 443 traffic to the ALB.
4. Internet traffic reaches the AWS Region.
5. The internet gateway provides the VPC internet path.
6. Public-subnet routing makes the ALB reachable.
7. Public-subnet NACL evaluates inbound traffic.
8. alb-sg evaluates inbound TCP 443.
9. ALB terminates the client connection.
10. ALB selects a healthy application target.
11. ALB creates a separate connection to target port 8080.
12. app-sg permits TCP 8080 from alb-sg.
13. Application-subnet NACL permits traffic.
14. Application processes the request.
15. Return traffic follows stateful SG tracking and permitted NACL rules.

Important:

The application does not see the original internet connection as a direct packet flow to its private IP. The ALB acts as the intermediary and establishes a separate backend connection.

22.2 Internet user directly to application private IP

Attempt:

Internet → 10.20.10.25

Result:

Not routable

Reasons:

10.20.10.25 is a private IPv4 address.
The private subnet has no direct internet-gateway route.
The instance has no publicly routable IPv4 destination.
The application security group allows traffic only from the ALB security group.

22.3 Application to database

Assumptions:

Application: 10.20.10.25
Database:    10.20.20.30
Port:        5432

Path:

1. Application resolves the database DNS name.
2. DNS returns a private database address.
3. Application sends TCP 5432 traffic.
4. Route table matches 10.20.0.0/16 → local.
5. Application SG outbound rule is evaluated.
6. Database-subnet NACL inbound rule is evaluated.
7. db-sg permits TCP 5432 from app-sg.
8. Database receives the connection.
9. Stateful security groups automatically recognize return traffic.
10. NACL return rules must still permit the response.

No internet gateway or NAT gateway is involved.

22.4 Private application to internet

Assumptions:

Application:   10.20.10.25
External API:  198.51.100.20:443
NAT Elastic IP: 203.0.113.10

Path:

1. Application initiates TCP 443.
2. app-sg outbound rules are evaluated.
3. Private-subnet outbound NACL rules are evaluated.
4. Private route table matches 0.0.0.0/0 → NAT Gateway A.
5. NAT translates the source address.
6. NAT public-subnet route uses 0.0.0.0/0 → internet gateway.
7. Traffic reaches the external API.
8. External API responds to the NAT public address.
9. NAT restores the private destination address.
10. Private-subnet inbound NACL permits the ephemeral destination port.
11. Stateful app-sg permits the connection response.
12. Application receives the response.

22.5 Internet trying to initiate through NAT

Attempt:

Internet client
→ NAT Elastic IP
→ Private application

Result:

Blocked

Reason:

The NAT gateway has no existing translation state created by an outbound connection from the private workload.

22.6 Application in one AZ using NAT in another AZ

Path:

Private App Subnet B
→ Cross-AZ path
→ NAT Gateway A
→ Internet gateway
→ Internet

Risks:

Cross-AZ dependency
Cross-AZ data processing
Loss of egress if AZ A fails
Reduced fault isolation

Corrected path:

Private App Subnet B
→ NAT Gateway B
→ Internet gateway
→ Internet

23. Network-Troubleshooting Method

Use this order. Do not randomly change security rules.

Step 1: Define the exact flow

Record:

Source resource:
Source address:
Destination resource:
Destination address:
Protocol:
Destination port:
Initiator:
Expected path:
Observed error:

Example:

Source:      EC2 app server
Source IP:   10.20.10.25
Destination: RDS PostgreSQL
Destination IP: 10.20.20.30
Protocol:    TCP
Port:        5432
Initiator:   Application server
Symptom:     Connection timeout

Step 2: Validate name resolution

Commands:

dig database.example.internal
nslookup database.example.internal
getent hosts database.example.internal

Questions:

Does the name resolve?
Does it resolve to the expected private address?
Is the application using the correct endpoint?
Is there a stale DNS record?

Step 3: Validate the application listener

On the destination:

sudo ss -lntp
sudo netstat -lntp

Check whether the application listens on:

0.0.0.0:PORT

or the correct private interface.

A service listening only on:

127.0.0.1:PORT

cannot accept remote connections.

Step 4: Validate route tables

Check the source subnet route table first.

Questions:

Which route matches the destination?
Is there a more specific conflicting route?
Is the target available?
Is the route in blackhole state?
Is the subnet associated with the intended route table?

Step 5: Validate security groups

Check:

Destination inbound rules
Source outbound rules
Correct protocol
Correct port
Correct CIDR or SG reference
Whether another attached security group adds unexpected access
Whether the expected source SG is actually attached

Step 6: Validate NACLs

Check both:

Source subnet NACL
Destination subnet NACL

Validate:

Forward-direction rule
Return-direction rule
Ephemeral ports
Rule ordering
Explicit deny rules
Correct subnet association

Step 7: Validate the operating-system firewall

Examples:

sudo nft list ruleset
sudo iptables -L -n -v
sudo firewall-cmd --list-all
sudo ufw status verbose

Step 8: Test progressively

Examples:

curl -v https://example.com
curl -v http://10.20.10.25:8080
nc -vz 10.20.20.30 5432
openssl s_client -connect example.com:443

A TCP timeout generally suggests dropped or unroutable traffic.

A connection-refused response usually means the host was reached, but no application accepted the connection on that port.

Step 9: Use Reachability Analyzer

Reachability Analyzer performs static configuration analysis between supported source and destination resources.

It can identify blocking components such as:

Route tables
Security groups
Network ACLs
Gateways
Load balancers
Network interfaces

It does not send live packets. It analyzes the configured network path.

Step 10: Use VPC Flow Logs

VPC Flow Logs capture metadata about IP traffic associated with VPC network interfaces.

They can help identify:

Accepted traffic
Rejected traffic
Source and destination addresses
Source and destination ports
Protocols
Unexpected traffic
Overly restrictive controls

Flow logs are collected outside the packet-forwarding path and do not reduce network throughput.

Typical actions:

ACCEPT
REJECT

A REJECT result can indicate a security-group or NACL decision, but further investigation is still required to identify the exact rule.

24. Common Failure Scenarios

Scenario 1: Public instance cannot access the internet

Possible causes:

No public IPv4 address
Missing internet-gateway route
Internet gateway not attached
Outbound SG restriction
NACL restriction
Host firewall
DNS failure

Scenario 2: Private instance cannot download packages

Possible causes:

No NAT gateway
Default route points to the wrong NAT gateway
NAT gateway failed or was deleted
NAT gateway is in a subnet without an IGW route
NACL return ports blocked
DNS resolution failure
Egress security-group restriction

Scenario 3: ALB reports unhealthy targets

Possible causes:

app-sg does not permit the ALB SG
Incorrect application port
Incorrect health-check path
Application bound only to localhost
Application not running
NACL blocks health checks
Target registered in the wrong port
Target belongs to an unavailable subnet or AZ

Scenario 4: Application cannot reach database

Possible causes:

Wrong database endpoint
Database SG does not allow app-sg
Wrong database port
Database not listening
NACL blocks traffic or return traffic
Application credentials invalid
Database is unavailable
DNS resolves to an unexpected address

Scenario 5: Security-group change did not block traffic immediately

Security groups use connection tracking. Existing tracked connections may behave differently from newly established connections.

Test using a new connection rather than assuming an existing persistent session proves the new rule is ineffective.

Scenario 6: NACL appears correct but connection times out

Common reason:

The forward port is allowed, but the return ephemeral-port range is blocked.

Scenario 7: New subnet unexpectedly has internet access

Cause:

The subnet was not explicitly associated with a custom route table and inherited the main route table, which contains an internet-gateway route.

Prevention:

Keep the main route table restrictive and explicitly associate every subnet.

Scenario 8: Workloads in AZ B lose internet during AZ A failure

Cause:

Both AZs use a zonal NAT gateway located in AZ A.

Prevention:

Deploy one zonal NAT gateway per Availability Zone or evaluate a Regional NAT Gateway.

25. AWS CLI Inspection Commands

VPCs

aws ec2 describe-vpcs

Filter by VPC:

aws ec2 describe-vpcs \
  --vpc-ids vpc-xxxxxxxx

Subnets

aws ec2 describe-subnets \
  --filters "Name=vpc-id,Values=vpc-xxxxxxxx"

Route tables

aws ec2 describe-route-tables \
  --filters "Name=vpc-id,Values=vpc-xxxxxxxx"

Internet gateways

aws ec2 describe-internet-gateways \
  --filters "Name=attachment.vpc-id,Values=vpc-xxxxxxxx"

NAT gateways

aws ec2 describe-nat-gateways \
  --filter "Name=vpc-id,Values=vpc-xxxxxxxx"

Security groups

aws ec2 describe-security-groups \
  --filters "Name=vpc-id,Values=vpc-xxxxxxxx"

Detailed security-group rules:

aws ec2 describe-security-group-rules \
  --filters "Name=group-id,Values=sg-xxxxxxxx"

Network ACLs

aws ec2 describe-network-acls \
  --filters "Name=vpc-id,Values=vpc-xxxxxxxx"

Network interfaces

aws ec2 describe-network-interfaces \
  --filters "Name=vpc-id,Values=vpc-xxxxxxxx"

26. Practical Laboratory

26.1 Objective

Build and validate a two-AZ, three-tier AWS network.

26.2 Required resources

Create:

One VPC
Six subnets
One internet gateway
One public route table
Two private application route tables
One isolated database route table
Two zonal NAT gateways for the full production model
Three security groups
At least one custom network ACL for testing
VPC Flow Logs
Reachability Analyzer paths

26.3 Network plan

VPC: 10.20.0.0/16

Public A:      10.20.0.0/24
Public B:      10.20.1.0/24
Private App A: 10.20.10.0/24
Private App B: 10.20.11.0/24
Database A:    10.20.20.0/24
Database B:    10.20.21.0/24

26.4 Build sequence

Create the VPC.
Enable DNS support and DNS hostnames where required.
Create two subnets per tier across two AZs.
Create and attach an internet gateway.
Create the public route table.
Add 0.0.0.0/0 → IGW.
Associate both public subnets.
Allocate Elastic IP addresses.
Create one NAT gateway in each public subnet.
Create one private application route table per AZ.
Route each private app subnet through its same-AZ NAT gateway.
Create an isolated database route table.
Associate both database subnets.
Create ALB, app and database security groups.
Launch temporary test resources.
Enable VPC Flow Logs.
Create Reachability Analyzer paths.
Execute expected-success and expected-failure tests.
Record results.
Delete chargeable resources after testing.

26.5 Required route tables

`rt-public`

10.20.0.0/16 → local
0.0.0.0/0    → Internet Gateway

Associations:

Public Subnet A
Public Subnet B

`rt-private-app-a`

10.20.0.0/16 → local
0.0.0.0/0    → NAT Gateway A

Association:

Private App Subnet A

`rt-private-app-b`

10.20.0.0/16 → local
0.0.0.0/0    → NAT Gateway B

Association:

Private App Subnet B

`rt-isolated-db`

10.20.0.0/16 → local

Associations:

Database Subnet A
Database Subnet B

26.6 Required tests

Test	Expected result
Internet → ALB TCP 443	Allowed
Internet → app TCP 8080	Blocked
Internet → database TCP 5432	Blocked
ALB → app TCP 8080	Allowed
App → database TCP 5432	Allowed
App → internet TCP 443	Allowed through NAT
Internet → app through NAT	Blocked
Database → internet	Blocked
Unapproved VPC resource → database	Blocked
AZ A private app → NAT A	Allowed
AZ B private app → NAT B	Allowed

26.7 Failure-injection exercises

Deliberately introduce and diagnose:

Remove the app subnet default route.
Point private subnet B to NAT gateway A.
Remove the ALB-to-app security-group rule.
Change the database SG source to the wrong SG.
Block ephemeral return ports in a custom NACL.
Remove the public-subnet route to the IGW.
Remove the test instance’s public IPv4 address.
Stop the application listener.
Associate a subnet with the wrong route table.
Delete a NAT gateway and inspect the route state.

For every failure, record:

Symptom
Expected path
Investigation
Root cause
Correction
Prevention
Monitoring recommendation

27. Architecture Decision Notes

Why use two Availability Zones?

Mitigates:

Single-AZ infrastructure failure
Localized power or networking failure
Planned maintenance impact
Loss of one application subnet
Loss of one zonal NAT gateway

Why use public load balancers?

Provides:

Controlled public entry point
TLS termination
Health checks
Backend distribution
Separation between public users and private workloads

Why keep application workloads private?

Reduces:

Direct attack surface
Public-IP management
Accidental exposure
Need for host-level internet access
Dependence on individual server firewall correctness

Why isolate databases?

Reduces:

Internet-exposure risk
Exfiltration paths
Unnecessary outbound connectivity
Effects of future public-routing mistakes

Why use security-group references?

Provides:

Logical service identity
Automatic accommodation of changing private IPs
Narrower access than VPC-wide CIDRs
Clear tier-to-tier relationships

Why use one zonal NAT gateway per AZ?

Mitigates:

Cross-AZ dependency
Loss of egress during another AZ’s failure
Unnecessary inter-AZ traffic
Poor fault isolation

Why keep the main route table restrictive?

Mitigates:

Accidental public routing for newly created subnets
Implicit route-table inheritance
Unreviewed internet exposure

28. Allowed and Forbidden Designs

Allowed

Public ALB in public subnets
Public NAT gateway in each active AZ
Private application servers without public IPs
Isolated database subnets
SG-to-SG references
Same-AZ zonal NAT routing
Explicit custom route-table associations
VPC endpoints for AWS service access
VPC Flow Logs for network evidence
Reachability Analyzer for configuration analysis

Forbidden without written justification

Public databases
Public application servers behind a load balancer
0.0.0.0/0 access to SSH
0.0.0.0/0 access to database ports
Shared cross-AZ zonal NAT presented as highly available
Database subnets routed directly to the internet gateway
Treating NAT as a firewall
Treating subnet names as proof of privacy
Permitting the entire VPC CIDR when SG references are sufficient
Making random SG and NACL changes during troubleshooting
Restrictive NACLs without documented return-port requirements
Using the default security group for production workloads
Leaving unused NAT gateways and Elastic IPs running

29. Interview-Level Questions

Question 1

What makes an AWS subnet public?

A subnet is public when its associated route table contains a route to an internet gateway. Resources still require appropriate public addressing and security rules for direct IPv4 internet communication.

Question 2

Can an EC2 instance in a public subnet access the internet without a public IPv4 address?

Not directly over IPv4 through the internet gateway. The instance requires a public IPv4 address or Elastic IP for direct IPv4 internet communication. Alternatively, it can use another egress mechanism such as NAT.

Question 3

Why is a public NAT gateway placed in a public subnet?

The NAT gateway must send translated internet-bound traffic to an internet gateway. Its subnet therefore requires a route to the internet gateway.

Question 4

Can an internet client connect to a private instance through a NAT gateway?

No. A NAT gateway permits response traffic for connections initiated by private resources. It does not provide unsolicited inbound forwarding.

Question 5

Why use one zonal NAT gateway per Availability Zone?

To preserve zonal fault isolation, avoid cross-AZ dependencies and prevent workloads in healthy zones from losing egress when the NAT gateway’s zone fails.

Question 6

What is the difference between a security group and a NACL?

A security group is a stateful resource-level allow-list. A NACL is a stateless subnet-level filter that supports allow and deny rules and processes them in numerical order.

Question 7

Why do NACLs require ephemeral-port rules?

Because they are stateless. Return traffic is evaluated separately and normally targets the initiating client’s ephemeral port.

Question 8

Does referencing a security group create network connectivity?

No. It authorizes traffic matching the rule, but route-table connectivity and other network controls must still exist.

Question 9

Does attaching a restrictive SG override a permissive SG?

No. Rules from multiple attached security groups are aggregated. A permissive rule in any attached group can permit the traffic.

Question 10

How would you troubleshoot an application timeout to a database?

Confirm endpoint and DNS.
Confirm the database is available and listening.
Check the source subnet route.
Check application SG outbound rules.
Check database SG inbound rules.
Validate source SG references.
Check both subnet NACLs and return ports.
Check host and database-level firewalls.
Use Reachability Analyzer.
Review VPC Flow Logs.

30. Knowledge Check

Answer without notes.

What is the scope of a VPC?
What is the scope of a subnet?
Can a subnet span two Availability Zones?
How many addresses does AWS reserve in an IPv4 subnet?
What determines whether a subnet is public?
Why does a public-subnet EC2 instance still need a public IP?
What does the VPC local route do?
What happens when a subnet has no explicit route-table association?
What is longest-prefix matching?
What does 0.0.0.0/0 mean?
Why does a database subnet normally lack a default internet route?
Why does a NAT gateway require an internet path?
Can NAT receive unsolicited internet connections?
Why should private subnet A use NAT gateway A?
What happens if NAT gateway A’s AZ fails?
Are security groups stateful?
Can security groups contain deny rules?
What happens when multiple SGs are attached?
Are NACLs stateful?
How are NACL rules ordered?
Why must a NACL permit return traffic?
When is an SG reference better than a CIDR?
Why is 0.0.0.0/0 on SSH dangerous?
What can Reachability Analyzer identify?
What information do VPC Flow Logs provide?
What is the difference between a timeout and connection refusal?
Why should the main route table remain restrictive?
How can VPC endpoints reduce NAT costs?
What network component provides outbound-only IPv6 internet access?
What failure does a multi-AZ network actually mitigate?

31. Completion Standard

This section is complete only when you can perform all of the following without referring to notes:

Draw the two-AZ, three-tier VPC architecture.
Calculate basic subnet ranges.
State the five AWS-reserved subnet addresses.
Classify a subnet by inspecting its route table.
Write all four required route tables.
Explain longest-prefix matching.
Trace internet-to-ALB traffic.
Trace ALB-to-application traffic.
Trace application-to-database traffic.
Trace private-application internet egress.
Explain why NAT does not permit unsolicited inbound traffic.
Explain zonal versus Regional NAT Gateways.
Design least-privilege SG rules.
Explain SG connection tracking.
Write a valid stateful-security-group explanation.
Write a valid stateless-NACL explanation.
Identify required ephemeral-port rules.
Diagnose at least five deliberately broken network paths.
Explain the security boundary of each subnet tier.
State what failure every component mitigates.

Required final output

Produce a one-page architecture record containing:

1. VPC CIDR
2. Subnet CIDRs
3. Availability Zone placement
4. Route-table definitions
5. Internet gateway purpose
6. NAT design
7. Security-group relationships
8. NACL strategy
9. Allowed traffic flows
10. Forbidden traffic flows
11. High-availability decisions
12. Cost considerations
13. Known limitations
14. Failure scenarios
15. Troubleshooting evidence
